EH series Illuminated push button switch

LED illuminated Split Face

Split-Face illumination type is divided into two parts in the middle,
up and down(horizontal) or left and right(vertical).

Red(70) upper part   Green(80) Lowe part     ALL LEDs illuminated
eh-w2reh-w2geh-w2eh-w1
Click an image to see lighting ON, and double click to see lighting OFF.

LED illuminated Dual-color

Dual-color type is illuminated two color illumination and another color illuminating available
by simultaneously lighting two LEDs.

Red(70) only     Green(80) only   Simultaneously lighting Two LEDs
eh-70eh-80eh-90
Click an image to see lighting ON, and double click to see lighting OFF.

Spot LED illuminated

Spot LED is illuminated only partly.
Surface of the button does not illuminate.

Red(70)
eh-spot
Click an image to see lighting ON, and double click to see lighting OFF.

Illumination differences by a combination of button and filter

Color button
(as same LED color)
Color button
(Milk-white)
Clear button
with filter
(as same LED color)
Clear button
with
Milk-white filter
eh-bn-r eh-bn-m eh-bn-c eh-bn-c
Without filter Without filter eh-fr-r eh-fr-m
eh-set-r sh-set-m eh-set-cr eh-set-cm
Lighting ON = Red
Lighting OFF = Red
Brightly color illuminating
by Red color button.
Lighting ON = Red
Lighting OFF = Milk
Softly color illuminating
by Milk color button.
Lighting ON = Red
Lighting OFF = Red
Brightly color illuminating
by Red color filter.
Lighting ON = Red
Lighting OFF = Milk
Softly color illuminating
by Milk color filter.

Click an image to see lighting ON, and double click to see lighting OFF.
